Y-Strainers — Flanged AISI 316
AISI 316 stainless steel Y-strainers with 18-mesh removable sieve for inline filtration in water, steam and light industrial pipelines. Flanged ends to EN 1092-1 PN16. DN50 to DN150.
📘 MT 2026 Catalogue
Flanged Y-strainers in AISI 316 stainless steel
MT Y-strainers provide efficient inline filtration for water, steam, gas and industrial fluids. The AISI 316 body and 18-mesh stainless steel sieve deliver corrosion resistance and reliable particle retention across a wide temperature range.
⬜ DN50–DN80
AED 265–437
AISI 316 body · 18-mesh SS sieve · 0.8 mm aperture · Flanged PN16
🟡 DN100
AED 563
AISI 316 body · 18-mesh SS sieve · Flanged PN16 · Medium pipeline
🔵 DN150
AED 1,017
AISI 316 body · 18-mesh SS sieve · Flanged PN16 · Large pipeline
Blow-off plug at the strainer pocket allows in-situ cleaning without pipeline shutdown. Mesh aperture 0.8 mm (18 mesh). Body rated to PN16 per EN 1092-1. Temperature range −10 °C to +150 °C. Suitable for water, light oils and non-aggressive chemicals.
Body Material
AISI 316 / 1.4401
CF8M cast equivalent
Screen
18-mesh SS sieve
0.8 mm aperture
Removable & cleanable
Connections & Rating
DN50–DN150
EN 1092-1 PN16
Flanged ends
Certifications
CE
PED 2014
EN
1092
1092
EN 1092
Size
5 references
Flanged Y-Strainer AISI 316 18-Mesh SS Sieve DN50 PN16 2"
REF. 5110050
FROM
AED265.08
AED 378.69−30% · Save AED 113.61
VIEW SIZES →
Flanged Y-Strainer AISI 316 18-Mesh SS Sieve DN65 PN16 2½"
REF. 5110065
FROM
AED387.14
AED 553.06−30% · Save AED 165.92
VIEW SIZES →
Flanged Y-Strainer AISI 316 18-Mesh SS Sieve DN80 PN16 3"
REF. 5110080
FROM
AED437.30
AED 624.71−30% · Save AED 187.41
VIEW SIZES →
Flanged Y-Strainer AISI 316 18-Mesh SS Sieve DN100 PN16 4"
REF. 5110100
FROM
AED563.27
AED 804.67−30% · Save AED 241.40
VIEW SIZES →
Flanged Y-Strainer AISI 316 18-Mesh SS Sieve DN150 PN16 6"
REF. 5110150
FROM
AED1016.93
AED 1452.76−30% · Save AED 435.83
VIEW SIZES →
